6mm 520nm 5mW 10mW Green Light Laser Module Point Laser Module Positioning
6mm 520nm 5mW 10mW Green Light Laser Module Point Laser Module Positioning
Regular price
$43.00
Regular price
$46.00
Sale price
$43.00
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
6mm 520nm 5mW 10mW Green Light Laser Module Dot Laser Module Positioning
Specification:
Dimensions: ф6* 24mm (Copper + Driver Board)
Output Wavelength: 520±10nm
Lens Material: Acrylic Optical Mirror
Output Power: <10mw
Circuit Control: APC Constant Power Control Board
Working Voltage: DC=3V-5V
Working Current: <120mA
Service Life: > 10000 Hours
Working Temperature: -20 ° C ~ +60 ° C
Storage Temperature: -40 ° C ~ +85 ° C
Output Wavelength: 520±10nm
Lens Material: Acrylic Optical Mirror
Output Power: <10mw
Circuit Control: APC Constant Power Control Board
Working Voltage: DC=3V-5V
Working Current: <120mA
Service Life: > 10000 Hours
Working Temperature: -20 ° C ~ +60 ° C
Storage Temperature: -40 ° C ~ +85 ° C
Product Manual:
520nm laser can be started at low temperature, and the starting effect is better than 532nm laser For green laser pointers, laser flashlights, laser positioning, range finder, medical equipment, electronics production enthusiasts, etc.
520nm laser can be started at low temperature, and the starting effect is better than 532nm laser For green laser pointers, laser flashlights, laser positioning, range finder, medical equipment, electronics production enthusiasts, etc.
Package:
1*520nm Green Light Module
1*520nm Green Light Module
